MSI Mpg Z390 Gaming Plus

La placa gaming MSI Mpg Z390 Gaming Plus tiene socket Intel 1151 y soporta procesadores Intel de 8ª y 9ª generación.

Especificaciones:

• Processor
  • Supports Intel® Core? 9000 Series family/ 8th Gen Intel® Core? / Pentium® Gold / Celeron® processors for LGA 1151 socket
• Chipset
  • Intel® Z390 Chipset
• Memory
  • 4 x DDR4 memory slots, support up to 64GB
  • Supports DDR4 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) / 2800(OC)/ 2666/ 2400/ 2133 MHz
  • Supports Dual-Channel mode
  • Supports non-ECC, un-buffered memory
  • Supports Intel® Extreme Memory Profile (XMP)
• Slots
  • 2 x PCIe 3.0 x16 slots
  • 4 x PCIe 3.0 x1 slots
  • 1 x M.2 slot with E key for Integrated Intel® Wireless-AC(CNVi) module only
• Onboard Graphics
  • 1 x HDMI? port, supports a maximum resolution of 4096x2160@24Hz
  • 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
• Multi-GPU
  • Supports 2-Way AMD CrossFire? Technology
• Storage
  • Intel® Z390 Chipset
  • 6 x SATA 6Gb/s ports1
  • 2 x M.2 slot (Key M)1
  • M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices
  • M2_2 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices
  • Intel® Optane? Memory Ready2
  • M.2 slots and SATA ports share the bandwidth. Please refer user manual for details.
  • Before using Intel® Optane? memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.
• RAID
  • Intel® Z390 Chipset
  • Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
  • Supports RAID 0, RAID 1 for M.2 PCIe storage devices
• USB
  • Intel® Z390 Chipset
  • 2 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1x Type-A port and 1x Type-C port) on the back panel
  • 6 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 3.1 connectors)
  • 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)1
  • The CNVI_1 and JUSB2 share the same bandwidth. Please refer user manual for details.
• Audio
  • Realtek® ALC892 Codec
  • 7.1-Channel High Definition Audio
• LAN
  • 1 x Intel® I219-V Gigabit LAN controller
• Internal connectors
  • 1 x 24-pin ATX main power connector
  • 1x 8-pin ATX 12V power connector
  • 6x SATA 6Gb/s connectors
  • 3x M.2 slots (2 M-Key slots,1 E-Key slot)
  • 2x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
  • 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
  • 1x 4-pin CPU fan connector
  • 1x 4-pin Water Pump connector
  • 5x 4-pin system fan connectors
  • 1x Front panel audio connector
  • 2x System panel connectors
  • 1x Chassis Intrusion connector
  • 1x TPM module connector
  • 2x 4-pin RGB LED connectors
  • 1x Serial Port connector
  • 1x Clear CMOS jumper
• Back panel ports
  • PS/2 Combo Port
  • LAN
  • HD Audio Connectors
  • USB 2.0
  • DVI-D
  • HDMI
  • USB 3.1 Gen2 Type-A + C
  • USB 3.1 Gen1
  • MSI MPG Z390 GAMING PLUS back panel ports
• Dimensions
  • 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
  • ATX Form Factor
• Mounting
  • 9 mounting holes
• Operating System
  • Support for Windows® 10 64-bit
